swiftui-math/EXAMPLES.md

SwiftMath Examples

Square of sums

(a_1 + a_2)^2 = a_1^2 + 2a_1a_2 + a_2^2

MathJax: (a_1 + a_2)^2 = a_1^2 + 2a_1a_2 + a_2^2

SwiftMath:

Quadratic Formula

x = \frac{-b \pm \sqrt{b^2-4ac}}{2a}

MathJax: x = \frac{-b \pm \sqrt{b^2-4ac}}{2a}

SwiftMath:

Standard Deviation

\sigma = \sqrt{\frac{1}{N}\sum_{i=1}^N (x_i - \mu)^2}

MathJax: \sigma = \sqrt{\frac{1}{N}\sum_{i=1}^N (x_i - \mu)^2}

SwiftMath:

De Morgan's laws

\neg(P\land Q) \iff (\neg P)\lor(\neg Q)

MathJax: \neg(P\land Q) \iff (\neg P)\lor(\neg Q)

SwiftMath:

Log Change of Base

\log_b(x) = \frac{\log_a(x)}{\log_a(b)}

MathJax: \log_b(x) = \frac{\log_a(x)}{\log_a(b)}

SwiftMath:

Cosine addition

\cos(\theta + \varphi) = \cos(\theta)\cos(\varphi) - \sin(\theta)\sin(\varphi)

MathJax: \cos(\theta + \varphi) = \cos(\theta)\cos(\varphi) - \sin(\theta)\sin(\varphi)

SwiftMath:

Limit e^k

\lim_{x\to\infty}\left(1 + \frac{k}{x}\right)^x = e^k

MathJax: \lim_{x\to\infty}\left(1 + \frac{k}{x}\right)^x = e^k

SwiftMath:

Calculus

f(x) = \int\limits_{-\infty}^\infty\hat f(\xi)\,e^{2 \pi i \xi x}\,\mathrm{d}\xi

MathJax: f(x) = \int\limits_{-\infty}^\infty\!\hat f(\xi)\,e^{2 \pi i \xi x}\,\mathrm{d}\xi

SwiftMath:

Stirling Numbers of the Second Kind

{n \brace k} = \frac{1}{k!}\sum_{j=0}^k (-1)^{k-j}\binom{k}{j}(k-j)^n

MathJax: {n \brace k} = \frac{1}{k!}\sum_{j=0}^k (-1)^{k-j}\binom{k}{j}(k-j)^n

SwiftMath:

Gaussian Integral

\int_{-\infty}^{\infty} \! e^{-x^2} dx = \sqrt{\pi}

MathJax: \int_{-\infty}^{\infty} \! e^{-x^2} dx = \sqrt{\pi}

SwiftMath:

Arithmetic mean, geometric mean inequality

\frac{1}{n}\sum_{i=1}^{n}x_i \geq \sqrt[n]{\prod_{i=1}^{n}x_i}

MathJax: \frac{1}{n}\sum_{i=1}^{n}x_i \geq \sqrt[n]{\prod_{i=1}^{n}x_i}

SwiftMath:

Cauchy-Schwarz inequality

\left(\sum_{k=1}^n a_k b_k \right)^2 \le \left(\sum_{k=1}^n a_k^2\right)\left(\sum_{k=1}^n b_k^2\right)

MathJax: \left(\sum_{k=1}^n a_k b_k \right)^2 \le \left(\sum_{k=1}^n a_k^2\right)\left(\sum_{k=1}^n b_k^2\right)

SwiftMath:

Cauchy integral formula

f^{(n)}(z_0) = \frac{n!}{2\pi i}\oint_\gamma\frac{f(z)}{(z-z_0)^{n+1}}dz

MathJax: f^{(n)}(z_0) = \frac{n!}{2\pi i}\oint_\gamma\frac{f(z)}{(z-z_0)^{n+1}}dz

SwiftMath:

Schroedinger's Equation

i\hbar\frac{\partial}{\partial t}\mathbf\Psi(\mathbf{x},t) = -\frac{\hbar}{2m}\nabla^2\mathbf\Psi(\mathbf{x},t)
+ V(\mathbf{x})\mathbf\Psi(\mathbf{x},t)

MathJax: $i\hbar\frac{\partial}{\partial t}\mathbf\Psi(\mathbf{x},t) = -\frac{\hbar}{2m}\nabla^2\mathbf\Psi(\mathbf{x},t)

• V(\mathbf{x})\mathbf\Psi(\mathbf{x},t)$

SwiftMath:

Lorentz Equations

Use the gather or displaylines environments to center multiple equations.

\begin{gather}
\dot{x} = \sigma(y-x) \\
\dot{y} = \rho x - y - xz \\
\dot{z} = -\beta z + xy"
\end{gather}

MathJax: $\begin{gather} \dot{x} = \sigma(y-x) \ \dot{y} = \rho x - y - xz \ \dot{z} = -\beta z + xy" \end{gather}$

SwiftMath:

Cross product

\vec \bf V_1 \times \vec \bf V_2 =  \begin{vmatrix}
\hat \imath &\hat \jmath &\hat k \\
\frac{\partial X}{\partial u} & \frac{\partial Y}{\partial u} & 0 \\
\frac{\partial X}{\partial v} & \frac{\partial Y}{\partial v} & 0
\end{vmatrix}

MathJax: $\vec \bf V_1 \times \vec \bf V_2 = \begin{vmatrix} \hat \imath &\hat \jmath &\hat k \ \frac{\partial X}{\partial u} & \frac{\partial Y}{\partial u} & 0 \ \frac{\partial X}{\partial v} & \frac{\partial Y}{\partial v} & 0 \end{vmatrix}$

SwiftMath:

Maxwell's Equations

Use the aligned, eqalign or split environments to align multiple equations.

\begin{eqalign}
\nabla \cdot \vec{\bf E} & = \frac {\rho} {\varepsilon_0} \\
\nabla \cdot \vec{\bf B} & = 0 \\
\nabla \times \vec{\bf E} &= - \frac{\partial\vec{\bf B}}{\partial t} \\
\nabla \times \vec{\bf B} & = \mu_0\vec{\bf J} + \mu_0\varepsilon_0 \frac{\partial\vec{\bf E}}{\partial t}
\end{eqalign}

MathJax: $begin{eqalign} \nabla \cdot \vec{\bf E} & = \frac {\rho} {\varepsilon_0} \ \nabla \cdot \vec{\bf B} & = 0 \ \nabla \times \vec{\bf E} &= - \frac{\partial\vec{\bf B}}{\partial t} \ \nabla \times \vec{\bf B} & = \mu_0\vec{\bf J} + \mu_0\varepsilon_0 \frac{\partial\vec{\bf E}}{\partial t} \end{eqalign}$

SwiftMath:

Matrix multiplication

Supported matrix environments: matrix, pmatrix, bmatrix, Bmatrix, vmatrix, Vmatrix.

\begin{pmatrix}
a & b\\ c & d
\end{pmatrix}
\begin{pmatrix}
\alpha & \beta \\ \gamma & \delta
\end{pmatrix} =
\begin{pmatrix}
a\alpha + b\gamma & a\beta + b \delta \\
c\alpha + d\gamma & c\beta + d \delta
\end{pmatrix}

MathJax: $\begin{pmatrix} a & b\ c & d \end{pmatrix} \begin{pmatrix} \alpha & \beta \ \gamma & \delta \end{pmatrix} = \begin{pmatrix} a\alpha + b\gamma & a\beta + b \delta \ c\alpha + d\gamma & c\beta + d \delta \end{pmatrix}$

SwiftMath:

Cases

f(x) = \begin{cases}
\frac{e^x}{2} & x \geq 0 \\
1 & x < 0
\end{cases}

MathJax: $f(x) = \begin{cases} \frac{e^x}{2} & x \geq 0 \ 1 & x < 0 \end{cases}$

SwiftMath:

Splitting long equations

\frak Q(\lambda,\hat{\lambda}) =
-\frac{1}{2} \mathbb P(O \mid \lambda ) \sum_s \sum_m \sum_t \gamma_m^{(s)} (t) +\\
\quad \left( \log(2 \pi ) + \log \left| \cal C_m^{(s)} \right| +
\left( o_t - \hat{\mu}_m^{(s)} \right) ^T \cal C_m^{(s)-1} \right)

MathJax: $\frak Q(\lambda,\hat{\lambda}) = -\frac{1}{2} \mathbb P(O \mid \lambda ) \sum_s \sum_m \sum_t \gamma_m^{(s)} (t) +\ \quad \left( \log(2 \pi ) + \log \left| \cal C_m^{(s)} \right| + \left( o_t - \hat{\mu}_m^{(s)} \right) ^T \cal C_m^{(s)-1} \right)$

SwiftMath:
